Polat Dunnage Product Series
Our Container Dunnage Air Bags
We can manufacture container dunnage air bags in specific dimensions and pressure levels according to your needs. For detailed product information and international orders, visit our website ShowDunnage.com .
Featured Sizes:
60x60 cm (24x24 inch)
90x90 cm (36x36 inch)
100x100 cm (40x40 inch)
120x120 cm (48x48 inch)
Featured Sizes:
Wide size options from 60x90 cm to 120x260 cm
POLAT DUNNAGE / CATALOG
| Level | Max. Pressure | Application Area | Transport Mode |
|---|---|---|---|
| Polat L0 | 2 PSI | Lateral Void | Truck |
| Polat L1 | 2.5 PSI | Lateral Voids | Road / Intermodal (Container) |
| Polat L2 | 3-4 PSI | Lengthwise Voids | Rail / Intermodal (up to 33,750 kg) |
| Polat L3 | 6 PSI | Lengthwise Voids | Rail / Intermodal (up to 72,000 kg) |
| Polat L4 | 8 PSI | Lengthwise & Horizontal | Rail / Ocean (up to 85,000 kg) |
| Polat L5 | 10 PSI | Lengthwise & Horizontal | Rail / Ocean (up to 97,000 kg) |
| Size (inch) | Size (cm) | Void Size (inch) | Void Size (cm) |
|---|---|---|---|
| 24×24 | 60×60 | 8 | 20 |
| 24×36 | 60×90 | 8 | 20 |
| 24×48 | 60×120 | 8 | 20 |
| 24×60 | 60×150 | 8 | 20 |
| 24×66 | 60×165 | 8 | 20 |
| 36×36 | 90×90 | 12 | 30 |
| 36×48 | 90×120 | 12 | 30 |
| 36×60 | 90×185 | 12 | 30 |
| 36×66 | 90×165 | 12 | 30 |
| 36×72 | 90×180 | 12 | 30 |
| 36×84 | 90×210 | 12 | 30 |
| 36×96 | 90×240 | 12 | 30 |
| 36×102 | 90×260 | 12 | 30 |
| 40×40 | 100×100 | 14 | 35 |
| 40×48 | 100×120 | 16 | 35 |
| 48×48 | 100×120 | 16 | 40 |
| 48×60 | 120×150 | 16 | 40 |
| 48×66 | 120×165 | 16 | 40 |
| 48×72 | 120×180 | 16 | 40 |
| 48×84 | 120×210 | 16 | 40 |
| 48×96 | 120×240 | 16 | 40 |
| 48×102 | 120×260 | 16 | 40 |
